Polygon Tent
- Span range: 15m–40m
- No internal columns (clear span design)
- No internal columns (clear span design)
- Fire-retardant & waterproof PVC fabric
Application:Ideally suited for a wide range of applications, including large-scale warehousing, major concerts, high-end exhibitions, and special events.
WHAT IS a POLYGON TENT?
A polygon tent is a type of advanced clear span tent structure system designed with a multi-sided aluminum frame. Unlike traditional A-frame tents, it provides a larger unobstructed interior space without internal support columns.
It is widely used in large-scale outdoor events, exhibitions, sports facilities, temporary warehouses, and high-end commercial applications.
From an engineering perspective, polygon tents belong to the category of modular event structures, which combine flexibility, scalability, and structural strength in one system.
Clear Span Design
Our A-frame structures eliminate interior support poles, maximizing usable floor space for storage, equipment, seating, and operational layouts.
Commercial-Grade Materials
Manufactured using 6061-T6 aluminum frame systems paired with durable PVC membrane covers designed for demanding commercial environments.
Modular Expandability
Tent lengths can be extended and configured to meet changing project requirements, making these systems ideal for scalable operations.
Long-Term Performance
Built for repeated use or extended deployment with low maintenance requirements.
Designed For Commercial Applications
Technical Specifications
| Type | 20m | 25m | 30m | 40m | ||||
| Span Width (m) | 5 | 5 | 5 | 5 | ||||
| Ridge Height (m) | 8 | 9.7 | 10.4 | 12.6 | ||||
| Side Height (m) | 4 | 4 | 4 | 4 | ||||
| Roof Pitch (degrees) | 45 | 45 | 45 | 45 | ||||
| Main Profile（mm） | 204×120×4 | 256×120×5 | 300×120×5 | 300×120×5 | ||||
| Frame Material | High strength 6061-T6 aluminum alloy frame | |||||||
| Cover Material | PVC tarpaulin | |||||||
1.Clear span available between 15 to 40 meters, modular structure, the length is adjustable by 5m unit.
2.SUPERB TENT custom builds each tent to your specifications. For details regarding customization, please feel free to consult our sales.
Structural Materials
Frequently Asked Questions
Get answers to the questions that matter most.
What exactly is a Polygon Tent?
A Polygon Tent fetures unique geomeric design, typically with multiple sides (like hexagon, octagon, or other polygonal shapes) that provide a modern,striking appegrance.These tents are designed for both outdoor and indoor use, offering a spacious and stylish environment for events,exhibitions, or brand activations.
Can the Polygon Tent withstand different weather conditions?
Yes, Polygon Tents ere designed to be weather resistant. The materials are waterproof, UV-resistant, and capable of withstanding wind speeds of up to 120km/h.
Can the Polygon Tent be branded with my company's logo?
Absolutey!The fabric panels of the Polygon Tent can be fully customized wth you logo,grophics, or messaging. This is idea for brand activations, marketing events,and exhibitions where visibility is key. You can also customize the color and design of the tent to match your brand identity.
What are the materials used in the construction of the Polygon Tent?
The Polygon Tent is made from a durable, UV-resistant polyester fabric with a PVC coating for waterproofing. The frame is typically constructed from lightweight aluminum or steel, which provides strength and stability while keeping the tent easy to transport.
What is the lifespan of polygon tents?
Typically 8–15 years depending on usage and maintenance.
